Capacitor Bushing Insulators
2017-09-09 20:14:00

IEC standard capacitor bushing insulators with color grey for LV, MV capacitors

We export big quantity of such bushings to European countries , American countries etc., most of customers are capacitor factories .

The bushing can be with hollow bolt or solid bolt , the bolt material can be brass or stainless steel .

The connection wire can be made of solid copper wire or flexible copper wire .

The bushing basic insulation level can be 110 BIL , 125 BIL , 170BIL, related applicable voltage level is 15kV ,27KV , 35 KV, 46 KV etc.



Applications:

The HIVOLT capacitor bushings are mainly used for insulation parts for power capacitors .

It can provide excellent insulation performance and strong mechanical support .



Competitive Advantage:

The bushing has very low leakage rate ,  very high mechanical cantilever strength .

The bushing finish are very shinning , without any surface defects .

We do routine test on each bushings after production to sort defect units out .

The related test items includs water pressure test , cantilever load withstand test , torsional strength test etc.

We can also design and develop new models based on different end user's requirements.
